500Mbps+ | Gigabit | 18dBi | 5KM
Model: WIS-L518AC
| Model | WIS-L518AC | ||||
| CPU | QCA9563+QCA9882+AR8033 | ||||
| Flash | SPI NOR 16MB | ||||
| DDR | DDR2 64MB | ||||
| 5G working frequency | 5.150GHz～5.850GHz (Debug mode: 4.9~6.1GHz) | ||||
| 5G band width | 5/10/20/40/80MHz | ||||
| 5G WiFi protocol | 802.11 a / n /ac | ||||
| Max rate | 866Mbps | ||||
| Antenna | Dual polarized flat directional antenna gain: 18dBi | ||||
| 5G TX Power | 802.11a | 54M | 24±2dBm | 6M | 27±2dBm |
| 802.11n HT20 | MCS7 | 23±2dBm | MCS0 | 26±2dBm | |
| 802.11n HT40 | MCS7 | 22±2dBm | MCS0 | 25±2dBm | |
| 802.11ac | MCS9 | 21±2dBm | MCS0 | 24±2dBm | |
| 5G Receiving Sensitivity | 802.11a | 54M | -72dBm | 6M | -92dBm |
| 802.11n HT20 | MCS7 | -70dBm | MCS0 | -89dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -87dBm | |
| 802.11ac | MCS9 | -58dBm | MCS0 | -85dBm | |
| 5G EVM | 802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB | ||||
| ppm | ±20ppm | ||||
| WAN | 1*10/100/1000M WAN, support 24V POE power | ||||
| Power | PoE 24V/1A | ||||
| Max Power Consumption | <10W | ||||
| Reset | Press 10 seconds for factory resetting. | ||||
| Indicators | Power, WAN, Signal*4 | ||||
| Dimension | 430mm*98mm*80mm | ||||
| Weight | 0.6kg | ||||
| Temperature | Working: -40°C to 65°C: Humidity: 5％～95％(Non-Condensing) | ||||
| IP Grade | IP66 | ||||
| ESD | 15kV | ||||
| Lightning Protection | 6kV | ||||
| Working mode | Access Point (Automatic WDS), Access Point (TDMA3), Site (WDS/TDMA3), Site (ARPNAT) | ||||
| Wireless | Intelligent dynamic polling, automatic channel selection, automatic modulation mode selection, automatic transmission power control (ATPC) | ||||
| Wireless Safety | WPA/WPA2 personal encryption, WPA/WPA2 enterprise encryption, WACL, user isolation | ||||
| Wireless QoS | TDMA implements 4 queue priority | ||||
| Network mode | IPv4 IPv6 | ||||
| VLAN | Support VLAN and VLAN transparent transmission | ||||
| WAN protocol | Static IP，DHCP client | ||||
| Service | DHCP service, SNMP service, NTP client, route tracking, ping watchdog | ||||
| Management | HTTP(S) GUI, SSH, SNMP read, WNMS, Telnet | ||||
| Built Tool | Site survey, connection testing, antenna calibration | ||||
| Built in Antenna | |||||
| Working frequency | 4.9-6.1GHz | ||||
| Gain | 18 dBi Sector | ||||
| Polarization mode | Vertical/horizontal dual polarization | ||||
| Horizontal beam angle | 90° | ||||
| Vertical beam angle | 90° | ||||
| Certification | CE/ROHS | ||||
WIS-L518AC
